Specification
| Electrical Characteristics(stc*) | |
| Model No. (SFM) | 580W |
| Maximum Power at STC(Pmax) | 580W |
| Maximum Power Voltage(Vmp) | 44.8 |
| Maximum Power Current(Imp) | 12.96 |
| Open Circuit Voltage(Voc) | 53.6 |
| Short Circuit Current(Isc) | 13.7 |
| Maximum System Voltage(V) | 1500V DC(IEC) |
| Maximum Series Fuse Rating(A) | 25A |
| Power Tolerance(%) | 0～+3% |
| NOCT | 45±2℃ |
| Pmax Temperature Coefficient | -0.46%/℃ |
| Voc Temperature Coefficient | -0.346%/℃ |
| Isc Temperature Coefficient | 0.065%/℃ |
| Operating Temperature | -40~+85℃ |
| *STC(Standard Test Condition):Irradiance 1000w/m2,module temperature 25℃,AM1.5 | |
| Best in Class AAA solar simulator(IEC 60904-9)is used,with power measurement uncertainty within ±3% | |
|
|
|
|
|
|
|
